Activation Electrically Max. working pressure 10 bar
Switching principle 5/2, with spring return Operational↩voltage 24 V DC
Actuating control Single Solenoid Voltage tolerance DC -15% / +20%
Manual override with detent Protection class with connection IP65
Pilot External Reverse polarity protection Protected against polarity reversal
Nominal flow Qn 850 l/min Sealing principle 16 mm, Soft seal
Min. working pressure -0.9 bar Power consumption DC 0.35 W Duty cycle 100 %
