Type   Poppet valve                                                          Permissible ripple    5%
Certificates   CE declaration of conformity                  Max. power consumption  300 mA
Working pressure max   12 bar                                      Protection class   IP65
Min. ambient temperature    0 °C                                  Electrical connection   via signal connection
Max. ambient temperature    50 °C                                Signal connection        input and output
Compressed air connection input    G 1/8, 1/8 NPT   Signal connection         Plug
MediumCompressed    air                                                Signal connection         M12
Nominal flow Qn       120 l/min                                      Signal connection          5-pin
Control              Analog                                              Actual output value       4 ... 20 mA
DC operating voltage   24 V                                            Nominal input               4 ... 20 mA
Hysteresis              < 0,05 bar                                          Regulation range min.   0 bar
Mounting orientation   ±α = 0 ... 90° ±β = 0 ... 90°
