• Activation     Electrically
  • Switching principle    2x 3/2 NC/NC, with spring return
  • Valve function              NC/NC
  • Manual override            with detent
  •               Pilot                             External
  • Nominal flow Qn     850 l/min
  • Min. working pressure  -0.9 bar
  • Max. working pressure  10 bar
  • Operational↩voltage  24 V DC
  • Voltage tolerance DC -15% / +20%
  • Protection class with connection    IP65
  • Reverse polarity protection    Protected against polarity reversal
