• Triple installation: Priority should be given to fixing it in the main pipeline of the gas source, ensuring that the filter is vertically downward (for easy drainage), the pressure reducing valve adjustment handwheel is easy to operate, and the oil level of the oil mist device oil cup is visible. Each interface needs to be wrapped with raw material tape or sealed with sealant to prevent air leakage.
    Electromagnetic valve connection: The outlet of the triple piece is connected to the inlet (P port) of the electromagnetic valve through a gas pipe. Pay attention to matching the specifications of the gas pipe (commonly φ 6, φ 8mm) to avoid bending or squeezing. It is recommended to install a muffler at the exhaust port (R/S port) of the solenoid valve to reduce noise.
    Pressure calibration: After introducing compressed air, first adjust the pressure reducing valve to the rated pressure of the equipment (such as 0.5MPa), observe whether the filter drain is draining normally, and whether the oil mist device oil volume meets the requirements (usually add 5-10 drops of lubricating oil every 10m ³ of airflow).
    Functional testing: Power on to test the action of the solenoid valve and check for any jamming or abnormal noise; Observe whether the actuator (such as cylinder) responds synchronously and confirm that there is no delay or leakage.
    Special reminder: Before installation, thoroughly blow the main pipeline to remove residual iron filings, welding slag, and other impurities; After a long-term shutdown and restart, manually drain the accumulated water in the three-way filter to prevent moisture from entering the solenoid valve with the airflow
